Jab Seeds Drillers Planters for Corn Beans Wheat Sorghum with Ground Piercing Punching Action and Handles Pulling:
The machine can sow corn, wheat, sorghum, beans, peanut, millet, cabbbage, turnip and many other different kinds of crops seeds. It can be fertilized and planted at the same time, and the amount of seed, the amount of fertilizer and the depth of sowing can be adjusted. No oil, no electricity, pure manpower model, easy to operate, you can learn in a few minutes.



The main parameters:
Dimensions (mm): 810*160*160 (L*W*H)
Weight (kg): 3
Sowing depth (mm): 35-78
Seed container capacity (kg): 1.2
Fertilizer container capacity (kg): 4
Seeding rate: 1-3 grains adjustable
Workers (person): 1



Instructions:
Grain seeding regulation:
One seed: insert the plug board on the two grains;
Two seeds: the sowing insert is inserted on top of one grain;
Tthree seeds: unplug the plug board.

Note: When adjusting the board, it must be adjusted when the seed box has no seeds. The planting depth can be adjusted up and down according to the soil humidity of the plot.



Fertilizer adjustment:
Pull out the adjustment block on the shaft and adjust it to the required amount of fertilizer.
Bean sowing adjustment: Move the clinker pressure pad under the scraping seed rubber to the direction of the seed shaft, remove the three screws, pass through the three holes at the back, and tighten, leaving a gap between the rubber and the shaft.
Shaft replacement method: without any tools, just unscrew the shaft head cover to take off the shaft head cover;
When the shaft head cover is put on, make sure the direction is correct.
